น้ำมันเกียร์อุตสาหกรรม Shell Omala S2 G 68, 100, 150, 220, 320, 460, 680, 1000

น้ำมันเกียร์อุตสาหกรรม Shell Omala S2 G

Previous Name: Shell Omala Oils

สำหรับใช้แทน Shell Omala S2 G, Castrol Alpha SP, Mobil Gear, PTT Gear EP, พีทีที เกียร์ อีพี, บางจาก เกียร์อุตสาหกรรม อีพี

Shell Omala S2 G

Industrial Gear Oils

x      EXTRA PROTECTION

x      STANDARD APPLICATIONS

Shell Omala S2 G oils are high quality extreme-pressure oils designed primarily for the lubrication of heavy duty industrial gears. Their high load carrying capacity and anti-friction characteristics combine to offer superior performance in gears.

 Performance Benefits

 x     Long oil life – Maintenance saving

 Shell Omala S2 G oils are formulated to resist thermal and chemical breakdown throughout the maintenance  interval.  They withstand  high thermal loading and resist the formation  of sludge to provide extended oil life capability, even with bulk oil temperatures of up to 100°C in certain applications.

x     Excellent wear & corrosion protection

 Excellent load carrying capacity reduces gear tooth and bearing wear on both steel and bronze components.

Shell Omala S2 G has excellent corrosion protection, protecting both steel and bronze components, even in the presence of contamination by water and solids.

x     Maintaining system efficiency

 Shell Omala S2 G oils have excellent water separation  properties,  such that excess water can be drained easily from lubrication systems to help extend the life of the gears and ensure efficient lubrication of the contact areas.

Water can greatly accelerate surface fatigue of gears and bearings as well as promoting ferrous corrosion on internal surfaces.  Water contamination should therefore be avoided or removed as quickly as possible after the occurrence.

Applications

 x      Enclosed industrial gear systems

 Shell Omala S2 G oils are formulated using an effective sulphur-phosphorus additive  system to provide an extreme pressure performance which allow trouble-free application in most enclosed industrial gearboxes using steel spur and helical gears.

x      Highly loaded gears

 Shell Omala S2 G oils have an effective full extreme  pressure (EP) additive  system allowing them to be used in highly-loaded gear systems.

x      Other applications

 Shell Omala S2 G oils are suitable for lubrication of bearings and other components in circulating and splash-lubricated systems

For highly-loaded worm drives the Shell Omala “W” series oils are recommended.

For automotive hypoid gears, the appropriate Shell Spirax Oil should be used.

Specifications and Approvals

• Meets ISO 12925-1 Type CKD, except ISO 680-1000
• Meets DIN 51517- Part 3 (CLP), except ISO 680-1000
• Meets AGMA 9005- EO2 (EP) Meets US Steel 224
• Meets David Brown S1.53.101,102,103,104
• Meets Cincinatti Machine P34,35,59,63, 74, 76-78

Health and Safety
Guidance on Health and Safety is available on the appropriate Material Safety Data Sheet, which can be obtained from your Shell representative.

Protect the Environment

Take used oil to an authorized collection point.  Do not discharge into drains, soil or water.

Advice

Advice on applications not covered in  this leaflet may be  obtained from  your  Shell representative.
